Drive Nitro RTL10266 - Rollator Operation; Adjustment of Brakes; Sitting Safely; Folding, Transport & Storage

Adjustment of Brakes
To adjust the braking
strength, adjust the
brake by pressing
the screw housing
downwards (figure 9)
and then turn left or
right (figure 10).
Sitting
Position the Nitro on an even and solid surface. Lock
the brakes (parking position). The Nitro must stand
and must not slip. Sit straight up and do not lean
backwards. (See figure 11).
Folding/Transport/Storage
To fold, pull seat
upwards by the handle
on the seat plate as
shown in figure 12. The
Nitro can now be folded
complete by pushing
the nitro together until
the mechanism is locked
under the seat. shown in
9 10
11
12 13
14
figure 13 & 14.
