Model:
Serial #:
Crane Commander Setting Sheet
(sheet 2 of 2)
CODE DESCRIPTION RANGE SET UNIT HOIST TRAVERSE NOTE
FIELD
SETTING
Fn44 Full Scale Meter Output 1-180Hz 0.1 Hz 60 Hz 60 Hz
Fn45 Meter Output Calibration 0~250 1 5 5
Fn46
Terminal #11 of main PCB
(TM2) or terminal #5 of D61530
(TB1) Multi-function select
0: 5th speed
1: RESET
2: 'Inch Commander'
3: 'Speed Commander'
4: 'Limit Commander'
(coast to stop)
5: 'Limit Commander'
(ramp to stop)
6: Emergency stop N/C
7: Base Block N/O
8: Acc./Dec. Time 2
- 0 0
Fn47
Terminal #7 of main PCB
(SP3) or terminal #4 of D61530
(TB1) Multi-function select
0: 4th speed
1: RESET
2: 'Inch Commander'
3: 'Speed Commander'
4: 'Limit Commander'
(coast to stop)
5: 'Limit Commander'
(ramp to stop)
6: Emergency stop N/C
7: Base block N/O
8: Acc/Dec time 2
- 0 0
Fn48 'Inch Commander' gain divisor 1~30 0.1 1 1
Fn49 Secondary accel time 0.1-800 sec. 0.1 sec. 2 sec. 3 sec.
Fn50 Secondary decel time 0.1-30 sec. 0.1 sec. 2 sec. 3 sec.
Fn51 Display mode 0~9 - 0 0
Fn52 Linear Speed Display 0-9999 - 1800 1800
Fn53
DC injection time* / Time delay
****
0/0.1-25.5 sec. / 0-10 sec. del. 0.1 sec. 2.0 sec. del.
2.0 sec.
injection
Fn54 DC Braking injection frequency 0/1~10Hz 0.1 Hz 0 2 Hz
Fn55 DC Braking level 0~20% 0.10% 0 5%
Fn56 'Command Link' Baud rate 0~3 - 2 2
Fn57
'Command Link' response
mode
0~7 - 1 1
Fn58
'Command Link' Transmit
object
0~33 - 0 0
Fn59 Elapsed time trip 0/0.5~999 hr 0.5 hr 0 0
Fn60
Frequency/Parameter lock
select
0 Normal
1 Freq. Lock
2 Parameter Lock
3 Freq. & Parameter Lock
- 0 0
Fn61 Fault sequence reference 1~4 - - -
Fn63 Elapsed time counter - - - -
Fn64 CPU version - - - -
Fn65 Prohibited Frequency (1) 0-180 Hz 0.1 Hz 0 Hz 0 Hz **
Fn66 Prohibited Frequency (2) 0-180 Hz 0.1 Hz 0 Hz 0 Hz **
Fn67 Prohibited Frequency (3) 0-180 Hz 0.1 Hz 0 Hz 0 Hz **
Fn68 Prohibited Frequency Range 0-5 Hz - 1 Hz 1 Hz **
Fn69 Motor Type 0~1 - 0 0 **
Fn70 Motor Rated Current See manual for reference 0.1A - - **
Fn71 Inverter Capacity Select 1~6 - - - **
Fn79 DEC stall prevention 1~8 1 3 **
Fn80 Raise enable current 0/30~100% 1% 0 0 **
Fn81 Lower enable current 0/30~100% 1% 0 0 **
Fn82 'Quick Pick' max. frequency 2~120Hz 0.1Hz 60Hz 60Hz **
Fn83
'Quick Pick' threshold
frequency
2~120Hz 0.1Hz 60Hz 60Hz **
Fn84 'Quick Pick' delay time 0.0~25.5 sec. 0.1 sec. 2 sec. 2 sec. **
Software version 10.6 or 20.4
CCSET1
* Only for Trolley / Bridge operation
** Only available on CC2110-2220, 4110-4220 models
*** Only available on CC204-275, 404-475 models
**** Only for Hoist operation
