Drolet Deco - Page 46

Deco Installation and Operation Manual
46
# Part # Description Qty / stove
1 AC01319 FIRE SCREEN DOOR 1
2 30569 ROUND WOODEN HANDLE BLACK 2
3 30025 1/4-20 X 1/2" PAN QUAD BLACK SCREW 1
4 30185 17/64" "AA" TYPE WASHER 1
5 30742 DRILLED BLACK WOODEN DOOR HANDLE 1
6 SE24235 CAST IRON DOOR WITH GASKET AND HANDLE 1
7 AC09196 HANDLE AND LATCH KIT 1
8 AC09185 DOOR LATCH KIT 1
9 AC06500 SILICONE AND 5/8" X 8' BLACK GASKET KIT 1
10 SE65275 REPLACEMENT GLASS WITH GASKET 9 13/16" x 19" 1
11 AC06400 BLACK SELF-ADHESIVE GLASS GASKET KIT (6') 1
12 PL65272 LEFT GLASS RETAINER 1
13 PL65270 TOP AND BOTTOM GLASS RETAINER 2
14 PL65271 RIGHT GLASS RETAINER 1
15 30124 SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC 10
16 SE65261 ASH DRAWER 1
17 PL65290 BOTTOM HEAT SHIELD 1
18 99999 BUILD TO ORDER 1
19 AC01335 AIR MATE 1
20 AC01334 FRESH AIR ADAPTER 1
21 SE45569 INSTRUCTION MANUEL KIT FOR DROLET DECO 1
22 30129 METAL SCREW #10 X 1/2" PAN QUADREX ZINC "A" TYPE 2
23 PL06728 AIR CONTROL HANDLE 1
24 PL65256 AIR DAMPER COVER 1
25 30138 METAL SCREW #6 3/8'' QUADREX ''A'' TYPE BLACK 2
26 30060
THREAD-CUTTING SCREW 1/4-20 x 1/2" F HEX STEEL SLOT
WASHER C102 ZINC
4
27 PL65277 AIR DAMPER COVER SUPPORT 2
28 30094 HEX SCREW WASHER HEAD 1/4-20 X 3/4" F ZINC TYPE 2
29 30428 BUSHING 2
30 SE65253 AIR CONTROL DAMPER 1
31 AC02050
ULTRA-QUIET 100 CFM BLOWER WITH VARIABLE SPEED
CONTROL
1
32 44085 RHEOSTAT KNOB 1
33 44087 RHEOSTAT NUT 1
34 44080 RHEOSTAT WITH NUT 1
35 60013 POWER CORD 96" X 18-3 1
36 44073 CROSSFLOW BLOWER 115V-60Hz-39W 100 CFM (P) 1
37 AC05530 THERMODISC KIT 1
38 44046 THERMODISC F110-20F 1
39 SE16059 ASH DUMP PLUG 1
40 29010 4 1/2" X 9" X 1 1/4" REFRACTORY BRICK 11
41 PL36027 3" X 9" X 1 1/4'' REFRACTORY BRICK 2
42 VP00020 4'' X 4 1/2" X 1 1/4'' REFRACTORY BRICK 2
43 PL36060 3 1/2" X 9'' REFRACTORY BRICK 1
44 PL36021 2 1/8" X 9" X 1 1/4'' REFRACTORY BRICK 2
45 29015 4'' x 9'' x 1 1/4'' REFRACTORY BRICK 4
