CLEARANCES
(SINGLE WALL PIPE)
CANADA USA
A
19" (483 mm) 19" (483 mm)
B
21" (533 mm) 21" (533 mm)
C
16" (406 mm) 16" (406 mm)
D
24½" (622 mm) 24½" (622 mm)
E
29¼" (743 mm) 29¼" (743 mm)
F
25¼" (641 mm) 25¼" (641 mm)
K
48" (1219 mm) 48" (1219 mm)
L
72" (183 cm) 72" (183 cm)
CLEARANCES
(DOUBLE WALL PIPE)
CANADA USA
A
12" (305 mm) 12" (305 mm)
B
21" (533 mm) 21" (533 mm)
C
12" (305 mm) 12" (305 mm)
D
17½" (445 mm) 17½" (445 mm)
E
29¼" (743 mm) 29¼" (743 mm)
F
21¼" (540 mm) 21¼" (540 mm)
K
48" (1219 mm) 48" (1219 mm)
L
72" (183 cm) 72" (183 cm)
Note: These clearances are also valid for an alcove installation.
Clearances for mobile homes
MOBILE HOME CLEARANCES (DOUBLE WALL
PIPE)
CANADA USA
A
13" (330 mm) 13" (330 mm)
B
21" (533 mm) 21" (533 mm)
C
12" (305 mm) 12" (305 mm)
D
18½" (470 mm) 18½" (470 mm)
E
29¼" (743 mm) 29¼" (743 mm)
F
21¼" (540 mm) 21¼" (540 mm)
K
48" (1219 mm) 48" (1219 mm)
L
84" (213 cm) 84" (213 cm)
