Savannah Installation and Operation Manual
50
Note that secondary air tubes (B) can be replaced without removing the baffle board (A).
Important Notes:
The air tubes are identified for placement as follows:
Model Type of tube
Savannah
Front ► 30 holes of 0.140"
Middle front ► 30 holes of 0.136’’
Middle rear ► 20 holes of 0.147’’
Rear ► 15 holes of 0.128’’
