Dromida DT4.18 BL - Radio Box; Shock Assembly

G
G
5
48
DOUBLE-SIDED TAPE
DOUBLE-SIDED TAPE
9. RADIO BOX
10. SHOCK ASSEMBLY
47
51
52
50
40
49
93
6
F
S
SCREW MUST BE SNUG
CENTER SERVO FIRST
SHOCK OIL
SHOCK OIL
SHOCK OIL
58
55
62
62
59
66
60
56
69
64
68
65
63
U
U
61
SHOCK OIL
1. Completely fill the
shock body with
shock oil.
2. Slowly move the
shaft up and down
to remove bubbles.
3. Slowly tighten the shock cap
onto the shock body to allow
any remaining air to escape.
