■ Power Assist System Check (1)
 Power assist system will not work normally if the battery is not installed and locked
in place.
 Check battery status before riding (Please refer to the next page battery lock
function & operation). Turn on the power first.
 Ensure all wires are good and all connections are securely locked and fastened.
 Don’t disassemble the bodywork, controller and panel without proper instruction.
■ Power Assist System Check (2) Battery Lock Function and Operation
CAUTION :
: :
:
 Put the battery into the frame and check whether it is inserted securely.
 Don’t remove the battery while starting the power
 When inserting the battery, listen for a click to indicate it was inserted correctly
1. Correct Position of Battery:
Stem handle is in the front
1
-
1. Battery Locked Up
Status
1
-
2. Battery
Take
up
Status
●Battery taking out steps
