146
Driving
06
The system is deactivated:
– Automatically above about 19 mph (30km/h)
(the image disappears temporarily from 12 mph
(20km/h)).
– By pressing the white arrow in the upper-left
corner of the touch screen.
AUTO mode
This mode is activated by default.
Using sensors in the front bumper, the automatic
view changes from the front view (standard) to
the view from above (zoom) as an obstacle is
approached during a manoeuvre.
Standard view
Obstacles may appear further away than
they actually are.
It is important to monitor the sides of the
vehicle during the manoeuvre, using the
mirrors.
Parking sensors also provide additional
information about the area around the vehicle.
180° view
The 180° view facilitates reversing out of a
parking space, making it possible to see the
approach of vehicles, pedestrians and cyclists.
This view is not recommended for carrying out a
complete manoeuvre.
It features 3 areas: left A, centre B and right C.
This view is only available via the view selection
menu.
360 Vision
The vehicle has a camera at the front, fitted in the
grille, and a camera at the rear, located close to
the tailgate opening control.
Using these cameras, the system displays the
vehicle's near surroundings on the touch screen,
offering views from the rear of the vehicle (rear
vision) when reverse gear is engaged and views
from the front of the vehicle (front vision) when
the gearbox is in neutral or a gear is engaged.
Rear vision
The system activates automatically when reverse
gear is engaged.
The system is deactivated:
– automatically above about 6 mph (10km/h).
– when shifting out of reverse (the rear view
image is replaced by the front view image after 7
seconds).
– by pressing the white arrow in the upper-left
corner of the touch screen.
If a trailer or a bicycle carrier is fitted to
the towball, the area behind the vehicle
on the view from above goes dark.
The surroundings are reconstructed by the
front camera only.
The rear vision views are similar to those for the
Reversing camera.
For more information on the Reversing camera,
refer to the corresponding section.
Front and rear vision
With the engine running and the speed
below 12 mph (20km/h), the system is
activated via the Driving/ Vehicle touch screen
menu:
► Select "Panoramic visual aid".
AUTO mode is displayed by default, with front
vision, if the gearbox is in neutral or with a gear
engaged, or with rear vision, if reverse is engaged.
