DS18 NXL-X600.4D User Manual

WIRING / CABLEADO
NXL-X1000.1D
+12V
SUB- SUB+
REM GND
Fusible marino para protección
contra corto circuítos inlcuído.
Marine fuse for short
protection included.
2 x 50A (100A)
1 CHANNEL SPEAKER CONNECTION
CONEXIÓN DE ALTAVOCES DE 1 CANAL
HEAD UNIT
BATTERY
UNIDAD CENTRAL
BATERÍA
SUBWOOFER-
CH SUB INPUTCH SUB INPUT
SUBWOOFER-
(1-4 OHMS)
SUBWOOFER+
6
