Step 7:Wrap the rubber pad around the pipe and align wire out hole According to the diagram.
Step 8: Push the wire into the tube, press on the rubber pad,and lock the the top clamp .
Step 9: Take down the safety rope and hang it on the pipe, lock the screw gasket safety rope lifting ring
on the clamp base, and apply screw fastening glue on the screw before locking.
Step 10: If need be ,rotate the speakers for best dispersion,this easily done by locating the 6mm&4mm
hex wrench set screw on the side of the clamp base,rotate the speaker / enclosure to the desired angel,
once there ... locking the screws tight , Avoid vibration ,clamp loose!!!
Step 7
Step 9
Rubber pad
INSTALLATION
