1 Speaker-Level Input:
These inputs get their signals from the speaker-level outputs of your
factory-installed source unit or amplifier
2 Ground:
Connect to a good, verified chassis ground.
3 +12 Volt:
Connect to a good, verified source of power.
4 Remote In:
Allows your V6HLPRO to be turned on remotely with a 12 Volt Signal.
5 Remote Out:
Outputs 12 Volts when your V6HLPRO is powerd up.
6 Clip Indicator:
This LED indicates when your signal level is just below clipping. This LED
should flicker occasionally when your system is playing at its maximum
volume level.
7 Power:
This light should be bright red when your system turns on.
8 Remote Subwoofer Level Control Input:
This input allows you to add the remote that will allow
you to control the subwoofer output from your dashboard.
9 Pre-Amp Output:
These RCA Connectors Should be connected to the next component, such as
signal processor, crossover or amplifier.
10 Level Controls:
These knobs allow you to adjust the signal level from your source unit to match
that of your aftermarket amplifiers.
11 Channel Summed Indicators:
Under the cover of your V6HLPRO are jumpers that will allow you to sum
selected channels into the main channels. The LED’s indicator let you know
which channels are being summed into the main inputs.
