DSC WS4920 User Manual

Table of Contents/ Table des matières/ Índice/ Indice dei contenuti
Installation Instructions.............................................................................................2
Instructions d’installation .......................................................................................10
Instrucciones de Instalación....................................................................................22
Instruções de Instalação..........................................................................................34
Istruzioni di installazione........................................................................................46
The WS4920 is compatible with the following DSC wireless devices:
NOTE: WS4920 is not compatible with 2-way devices.
Door/ Window Contact Alarm Panel Wireless Receiver
UL
WS4945
UL
WS4965
WS4975W*
EV-DW4975**
EV-DW4917
WS4925
EV-DW4955
UL
PC1616/PC1832/PC1864
UL
SCW9045-433
UL
SCW9047-433
UL
PC9155-433
UL
PC4020-433
PC4010-433
SCW9055-57(D)(G)(I)-433
UL
RF5132-433
UL
RFK5500-433
UL
RFK5501-433
UL
RFK5508-433
UL
RFK5516-433
UL
RF4164-433
PC5132-433
RF5108-433
RF5501-433
Motion Detector Wireless Key Smoke Detector
UL
WLS914-433
UL
WS4904(P)
WS4904M
UL
WS4939
WS4949
WS4959
WS4969
WS4979
***
UL
WS4916
***
UL
WS4926
Glassbreak Detector CO Detector Hold-Up Alarm
UL
WLS912L-433
***WS4913 WLS928-433
Shock Sensor Flood Sensor Panic Pendant
EV-DW4927
EV-DW4927SS
WS4985
UL
WS4938
WS4938-2W
UL
Only these UL/ULC listed devices are to be used with UL/ULC listed systems.
* Not available in North America, South America and New Zealand.
** Available in North America, South America and New Zealand only.
*** For Residential Fire installations, two WS4920’s must be used.

DSC WS4920 Specifications

General

Product color	White
Compatible products	ALEXOR, PowerSeries 9045/47, PowerSeries PC1616/PC1832/PC1864, . MAXSYS PC4010/PC4020 PC5132/RF5132/RF5108/. RFK5500/RF5501, MAXSYS RF4164 WS4945, WS4975 WS4904, WS4904P, WLS914-433 WLS912L-433 WS4913 WS4916 WS4938, WS4938-2W WS4939 WS4979
Battery low indication	Yes
RF transmission frequency	433.92 MHz
Number of devices supported	164
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	5 - 93 %
Input voltage	120 V
Battery voltage	4.8 V
Input frequency	50 Hz
Built-in battery	No
Operating current	0.1 A
Power source type	AC, Battery
Battery technology	Nickel-Metal Hydride (NiMH)

Weight and Dimensions

Depth	33.8 mm
Width	113.5 mm
Height	176.8 mm
Weight	- g
