Function description
9.5.3 Attempted vandalism
The behavior can be set via the parameter "Brake options".
o Refer to page 56, chapter 10.4.2.
Option "Brake on if vandalism" is
activated
Option "Brake always off"
is activated
9.5.4 Emergency
Once an attempt is made to move the locking element from the
home position, the brake is activated. If the locking element is
pushed or pulled with higher force than the holding force of the
brake, the brake will give and tighten again at once. This permits
using the locking element further in small steps. If the vandalism
attempt is cancelled, the locking element swivels back to the home
position.
The home position is only held by the motor torque. If pushing or
pulling the locking element at a higher force than the holding force
of the motor, the locking element can be swivelled against the
motor torque. Once the outer force on the locking element is
removed, the locking element turns back to the home position.
If the input IN1 "Emergency" is interrupted during operation, the
PRWRUL]HGJDWH enters a safe state. The motor powers down at
once. The control system returns to operation when there is
voltage at the input IN1 again.
