02/28/18
Designed Security, Inc.
www.dsigo.com * dsi@dsigo.com
Access Control 14
Access Control > Exit Alarm (EA) > ES4300A Series
Power 12 or 24 VAC/VDC @ 200 mA
Jumper Selectable
Local Control Key switch reset/bypass
Tamper switch (T1)
Control Input N/C door contact
N/O remote reset/bypass
Control Output N/O & N/C Intrusion/
Tamper Alarm Status LED
Adjustment Auto Reset 0-60 seconds
Adjustable Shunt Delay 0-20 seconds
Alarm 103 dB @ 3 ft
Mechanical SpeciÀ cations
Dimensions ES4300A-K0 4.6”w x 4.6”h x 2.30”d
ES4300A-K1 4.6”w x 4.6”h x 2.30”d
ES4300A-K2 4.6”w x 4.6”h x 2.30”d
ES4300A-K3 4.6”w x 4.6”h x 2.30”d
ES4300A-K4 4.6”w x 4.6”h x 2.30”d
ES4300A-K5 4.6”w x 4.6”h x 2.30”d
ES4300A-K6 4.6”w x 4.6”h x 2.30”d
ES4300A-K7 4.6”w x 4.6”h x 2.30”d
Key Switch Options
K0 No key switch
Finish
K1 Double bit
K2 Barrel
K3 Rim hardware with cylinder
K4 Rim hardware without cylinder
K5 Medeco
K6 DPDT
K7 Rim with small format interchangeable core cylinder (SFIC)
Painted - DSI Beige
Electrical SpeciÀ cations
