DTS XR 8 Spot - Technical Features of XR 8 Spot

ARC 1200
XR 8 SPOT
4
1- TECHNICAL FEATURES
The XR 8 Spot is fitted with a Philips MSR 575/2 discharge lamp
(GX9,5 lampholder base), with a colour temperature of 7,200 °K and a luminous flux of
49,000 Lumens.
Duration is 750 hours, with replacement recommended before 1000 hours
Other recommended lamps: Philips 575 MSD (6.000K°-49.000 Lumens-3.000 hours)
The unit incorporates:
Motorized Focus system
Zoom (3 selectable beam aperture angles 11° / 15° / 18° with auto-focus)
Dimmer (emitted light is controlled by progressive and linear dimming).
Shutter (instantaneous shutter opening/closure)
Strobe: mechanical strobe effect (frequency variable from 0.85 flashes/sec to 10
flashes/sec).
Gobo wheel (7 indexable 16 bit gobos + open)
Colour wheel (8 colours + open)
Prism (indexable 3 facet prism rotating in both directions)
Frost Filter
Electronic or magnetic ballast
Pan: 540° in 3.9 seconds (8 or 16 bit) with auto repositioning system
Tilt: 320° in 2.6 seconds (8 or 16 bit) with auto repositioning system
USITT Standard DMX 512 input
20 DMX channels
4 -eight digit- LED display with 4 buttons
2 XLR connectors (In and Out) with 3 and 5 pins selectable by user
Power supply
Electronic ballast:
Universal power supply 90 - 245 V (50/60 Hz)
Electromagnetic ballast:
230 V 50-60 Hz
Power consumption: 750 W.
Remote Lamp on/off via DMX
Operating ambient temperature -10° / 40°
Weight
26 Kg (XR8 SPOT E.B.)
Dimensions (HxDxL)
Projector (670x450x470)
Weight 26 Kg
Packing Dimensions
(HxDxL)
800 x 550 x 440 mm
Weight
33.3 Kg
