DTS XR8 SPOT - Pan & Tilt Card; Cables Resend Card; Display Card; Lamp On-Off Control Card

22-PAN & TILT CARD
DATA 1
DATA 2
(VIOLET)
(LIGHT GREEN)
MOTOR TILT
(BROWN)
DISPLAY 1
DISPLAY 2
ENCODER TILT
(ORANGE)
FROM J12
P&T PCB
24-DISPLAY CARD
V1V1
TCN0060
CN7
FROM J16
PAN & TILT
CARD
FROM J7
PAN & TILT
CARD
IN LAMP
OUT LAMP
24V
˜
If the PCB card doesn’ t work, move the cable
“IN LAMP” from CN 1 to CN 7
To remove error from display, in
Menu select
ARC 1200
XR 8 SPOT
BLACK RED
BLACK BLACK
23-CABLES RESEND CARD
25-LAMP ON-OFF CONTROL CARD
33
PAN
(WHITE)
TILT
(BROWN)
GND
(BLACK)
30 VDC
(RED)
FAN
(WHITE)
ENCODER TILT
(ORANGE)
ENCODER PAN
(RED)
DMX INPUT
(WHITE)
TO J1
8 MOTORS CARD
(GREEN)
TO J2
LAMP
ON-OFF
CARD
TO J1
DISPLAY CARD
(WHITE)
