Dual illumiNITE XIA3145 - Connections and Controls

4
XIA3145 INSTALLATION
Connections and Controls
Low Level Inputs
High Level Inputs
Input Level Control
Crossover Frequency
Crossover Mode Switch
Bass Boost
LED Indicator
1
2
3
Ground Connection
Remote Connection
+12VDC Battery Connection
Main Fuses
illuminite Fuse
Illuminite Outputs
Speaker Connections
1 2 3
4 5 6
7
14 13 12 11 10 9 8
4
5
6
7
8
9
10
11
12
13
14
