7
SD12 ENCLOSURE DIMENSIONS
Sealed Enclosure
Good Bass Performance
Mini-Enclosure
(Vb) Box Volume=.75 Cu. Ft.
Example
Dimensions: 14" W x 14" H x 11.5" D
Better Bass Performance
Small Enclosure
(Vb) Box Volume=1.00 Cu. Ft.
Example
Dimensions: 15" W x 14" H x 13" D
Best Bass Performance
Medium Enclosure
(Vb) Box Volume=1.25 Cu. Ft.
Example
Dimensions: 17" W x 15" H x 13" D
Note: All specifications are subject to
change without notice.
Attention/Notice:
Dimensions are external.
