Ducane 2HP14 - Cooling Performance with Evaporator Coils

2HP14SplitSystemHeatPump
seer
14
2HP14SplitSystemHeatPump
seer
14
CoolingPerformancewithEvaporatorCoils
Outdoor
Model
Indoor Model
Cooling Heating
Refrigerant
Connection
Refrigerant
Line Size
Indoor
Metering
Device
Piston or Field
Installed TXV
Factory
Installed TXV
Outdoor Indoor
Suction
Liquid
Req'd
Indoor
2
Orifice
Optional
Field
Installed
Orifice
SEER EER
Rated
ARI
Capacity
1
Rated
Sensible
Capacity
HSPF
47° 17°
CFM
Suction
Liquid
Suction
Liquid
Btuh COP Btuh COP
2HP14*24P E(C,H,M,U)1P29NA E(C,H,M,U)2T29NA 14.00 12.50 24,000 18,500 8.20 22,400 3.40 14,400 2.24 850
3/4
3/8
3/4
3/8 3/4 3/8 --- H2TXV01
2HP14*30P
E(C,H,M,U)1P36N(A,B,C)+TXV E(C,H,M,U)2T36N(A,B,C) 13.50 12.00 28,400 23,200 7.70 26,000 2.94 18,400 2.26 1050
3/4
3/8
3/4
3/8 3/4 3/8 --- H2TXV01
E(C,H,M,U)1P43NB+TXV E(C,H,M,U)2T43NB 13.50 12.00 29,000 23,600 7.70 26,000 2.94 18,200 2.24 1050
3/4
3/8
7/8
3/8 3/4 3/8 --- H2TXV01
E(C,M,U)1P48N(B,C)+TXV E(C,M,U)2T48N(B,C) 13.50 12.00 28,800 23,500 7.70 26,000 2.90 18,000 2.22 1050
3/4
3/8
7/8
3/8 3/4 3/8 --- H2TXV01
2HP14*48P
E(C,H,U)1P49NC+TXV E(C,H,U)2T49NC+TXV 14.00 11.50 47,000 38,700 8.20 45,500 3.60 26,400 2.18 1700 7/8 3/8 7/8 3/8 7/8 3/8 --- H2TXV02
E(C,M,U)1P62ND+TXV E(C,H,U)2T62ND 14.00 11.50 47,000 38,700 8.20 45,500 3.60 26,400 2.20 1700 7/8 3/8 7/8 3/8 7/8 3/8 --- H2TXV02
2HP14*60P
E(C,H,U)1P62NC+TXV E(C,H,U)2T62NC 13.00 12.00 53,000 44,000 7.70 52,000 3.30 32,000 2.30 1950 7/8 3/8 7/8 3/8 1-1/8 3/8 --- H2TXV02
E(C,H,U)1P62ND+TXV E(C,H,U)2T62ND 13.00 12.00 53,000 44,000 7.70 52,000 3.30 32,000 2.30 1950 7/8 3/8 7/8 3/8 1-1/8 3/8 --- H2TXV02
1
Certified in accordance with Unitary Air Conditioner Certification Program, which is based on ARI Standard 210/240.
2
Required to achieve ARI rating.
A blower time delay is required to achieve ARI rating.
* = B, L
