95% GAS FURNACE 95G1
Page 5
DIMENSIONS (IN.)
Model A B C D
UPFLOW / HORIZONTAL
95G1UH045BP08 17-1/2 16-3/8 16 7-5/8
95G1UH045BP12 17-1/2 16-3/8 16 7-5/8
95G1UH070BP12 17-1/2 16-3/8 16 7-5/8
95G1UH090CP12 21 19-7/8 19-1/2 9-3/8
95G1UH090CP16 21 19-7/8 19-1/2 9-3/8
95G1UH110CP16 21 19-7/8 19-1/2 9-3/8
95G1UH110CP20 21 19-7/8 19-1/2 9-3/8
95G1UH135DP20 24-1/2 23-3/8 23 11-1/8
DOWNFLOW
95G1DF045BP12 17-1/2 16-3/8 16 15-1/2
95G1DF070BP12 17-1/2 16-3/8 16 15-1/2
95G1DF090CP20 21 19-7/8 19-1/2 19
95G1DF110CP20 21 19-7/8 19-1/2 19
Front View
