RHP13 Package Heat Pump
HeatStripElectrical
Model No.
Heater
Model
Unit
Supply
Single Phase
Heater
kW
Minimum
Circuit
Ampacity
1
Maximum
Fuse / HACR
Brkr. 2
1
Minimum
Circuit
Ampacity
2
Maximum
Fuse / HACR
Brkr.
2
RHP13A24P
RHP13A30P
RHP13A36P
AHSA05A
240 5.0 31.2 35 ---- ---
208 3.7 27.8 30 ---- ---
AHSA07A
240 7.0 41.7 50 ---- ---
208 5..3 36.8 40 ---- ---
AHSA010A
240 10.0 57.3 60 ---- ---
208 7.5 50.3 60 ---- ---
AHSA015A
240 15.0 57.3 60 26 30
208 11.3 50.3 60 22.5 25
RHP13A42P
RHP13A48P
RHP13A60P
AHSA05A
240 5.0 33.3 35 ---- ---
208 3.7 29.9 30 ---- ---
AHSA07A
240 7.0 43.8 50 ---- ---
208 5..3 38.9 40 ---- ---
AHSA010A
240 10.0 59.4 60 ---- ---
208 7.5 52.4 60 ---- ---
AHSA015A
240 15.0 59.4 60 26 30
208 11.3 52.4 60 22.5 25
AHSA20A
240 20.0 59.4 60 52.1 60
208 15.0 52.4 60 45.1 50
HeatStripElectric
Accessories
Description Where Used Kit Number
5 kW Electric Heater All Models AHSA05A-1
7 kW Electric Heater All Models AHSA07A-1
10 kW Electric Heater All Models AHSA10A-1
15 kW Electric Heater All Models AHSA15A-1
20 kW Electric Heater 42, 48 & 60 AHSA20A-1
Roof Curb 24, 30 & 36 ACURB161-1
Roof Curb 42, 48 & 60 ACURB163-1
Manual Fresh Air Damper 24, 30, 36 ADMPR145-1
Manual Fresh Air Damper 42, 48, 60 ADMPR166-1
Motorized Fresh Air Damper 24, 30, 36 ADMPR146-1
Motorized Fresh Air Damper 42, 48, 60 ADMPR167-1
Downflow Economizer 24, 30, 36 AECON825-1
Downflow Economizer 42, 48, 60 AECON826-1
Horizontal Economizer 24, 30, 36 AECON827-1
Horizontal Economizer 42, 48, 60 AECON828-1
SoundRatings
Model No.
Sound
dBA
RHP13A24P 77
RHP13A30P 77
RHP13A36P 77
RHP13A42P 80
RHP13A48P 80
RHP13A60P 80
FieldProvided1"
FilterDimensions
Small Base 2, 2.5, 3 Ton
24" width
28" height
Large Base 3.5, 4, 5 Ton
30" width
30" height
