5. Lay the PCIII in the tail section
temporarily.
6 Route the PCIII harness through the
hole in the tail section (Fig. C).
7. Route the PCIII along the right hand
side of the subframe. Secure the PCIII
harness to the subframe using 2 of the
large supplied zip ties (Fig. D).
Fig. B Fig. AFig. CFig. D
i736-411 www.powercommander.com 2008 Ducati 1098R - PCIII USB - 2
Zip ties
PCIII harness
1. Remove the seat and solo cover.
2. Remove the cover around the fuel
tank (Fig. A).
3 Remove the fuel tank
4. Remove the inner fairing cover on
the right hand side (Fig. B).
