STANDARD factory setting is as follows:
compression: 12 clicks;
rebound: 11 clicks.
Max. setting range for softest damping adjustment is 14
clicks (both for rebound and compression).
To change the preload of the spring inside each fork leg,
turn the hex. adjusting nut (2) with a 22-mm hexagon
wrench.
Preload setting range (A, fig. 17.1) is from 25 to 10 mm.
Factory setting is 20 mm.
Important
Adjust both fork legs to same settings.
