Ducati 996 - Adjusting Headstock Angle

46
E
Adjusting headstock angle (fig. 33.1)
Loosen the two screws (1) on the frame r.h. side to
adjust the headstock angle.
Fully unscrew the screw (2) and turn the headstock end
(3) by 180° with a pin wrench.
Fully screw the screw (2). Grease the screw threadings
(1) with SHELL Retinax HDX2 and tighten to 22
Nm/16.22 ft.lbs.
Note
While performing the above, the handlebars should
not be fully turned.
When finished, the steering damper must be
repositioned. Undo the screw (4, fig. 33.2). Move the
damper rod joint to the frame hole (5). Tighten the screw
(4) previously removed.
Important
The steering lock can be used only if the headstock
tube is positioned at 24°30’. This adjustment is possible
for 748S, 996 and 996S models only.
fig. 33.1
fig. 33.2
