Reassembly:
insert the locating pegs of the bulb base into their seats
to obtain correct alignment.
Hook the clip (4, fig. 35.2) to the headlamp holders;
reconnect the cables and refit the rubber cover (1, fig.
35.2).
To change the parking light bulb, the headlamp fairing
must be removed first (see page 39).
Undo the horn fastening screw and remove the horn. Pull
out the bulb holder (5, fig 35.3) from the rim-reflector
assembly.
Remove the bulb and fit a new one.
fig. 36
5
Instrument panel (fig. 36)
Remove the headlamp fairing (see page 39) to reach the
instrument panel bulbs.
One or two lamps are fitted under each instrument. Pull
out the bulb holder (1) under the instrument involved,
remove the bulb and fit a new one.
fig. 35.3
