DLM 4601-5101T-5301-5301P-5301E LAWN MOWER
DLM 4601
1. Engine 5. Side discharge 9. Fixing knob
2. Front cover 6. Deck 10. Panel
3. Bumper 7. Height adjustment handle 11. Brake lever
4. Wheel 8. Half plastic box 12. Clutch lever
DLM 5101T
1. Engine 4. Side discharge 7. Brake lever
2. Deck 5. Height adjustment handle
3. Wheel 6. Fixing knob
