DLM 4601-5101T-5301-5301P-5301E LAWN MOWER
DLM 5301 - DLM 5303
1. Engine 5. Side discharge 9. Fixing knob
2. Front cover 6. Deck 10. Panel
3. Bumper 7. Height adjustment handle 11. Brake lever
4. Wheel 8. Half plastic box 12. Clutch lever
DLM 5301P
1. Engine 5. Side discharge 9. Fixing knob
2. Front cover 6. Deck 10. Panel
3. Bumper 7. Height adjustment handle 11. Brake lever
4. Wheel 8. Half plastic box
