Ducati MONSTER 1200 s User Manual

Left-hand switch
1) Dip switch, two-position light selector switch:
position
= low beam ON (A);
position
= high beam ON (B);
position
= high beam (FLASH) and
instrument panel control (C).
2) Switch
= 3-position turn indicator control:
centre position = OFF;
position
= left turn;
position
= right turn.
To disable the turn indicator, press the control
once it returns to centre position.
3) Button
= warning horn.
4) Instrument panel control switch, position "
".
5) Instrument panel control switch, position "
".
4
A
B
C
2
1
3 5
Fig. 100
172

Ducati MONSTER 1200 s Specifications

General

Displacement	1198.4 cc
Power	147 hp (108 kW) @ 9, 250 rpm
Torque	124 Nm (91.5 lb-ft) @ 7, 750 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
ABS	Bosch Cornering ABS
Traction Control	Ducati Traction Control (DTC) EVO
Riding Modes	Sport, Touring, Urban
Seat Height	810 mm (31.9 in)
Engine Type	L-Twin, 4 valves per cylinder, Desmodromic
Front Suspension	Öhlins 48 mm fully adjustable usd fork
Rear Suspension	Öhlins fully adjustable monoshock unit
Front Brake	2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc M50 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Dry Weight	185 kg
Fuel Tank Capacity	16.5 liters (4.4 US gal)
