Motore / Engine 143
ENGINE DISASSEMBLY
SEQUENCE
This diagram shows the
recommended sequence for
disassembling the engine
components.
Identify the component to be
disassembled and follow the arrows
for the parts to be removed.
Generator
cover
Generator
rotor
Flywheel and
starter clutch
Timing lay gear
Timing gear
Starter idle gear
Starter motor
Timing lay
shaft
Pump rotor
Stator
Gear selector
lever
Gear stopper
Crankcase
opening
Crankshaft
Connecting rods
Connecting rod
bearings
Support bearings
Intake
manifold
Timing belt
rollers
Camshaft
support
Valves
Water
connectors
Belts
Head
Cylinder
Piston
Water pump
cover
Camshaft
Rollers on
timing lay shaft
ENGINE
Pressure plate
Clutch plates
Drum with cush
drive hub
Clutch
housing
Primary gear
Oil pump
Crankshaft gear
Gear selector forks
Fork shaft
Gearbox shafts
Gearbox
shafts gears
RH cover
Pressure
relief valve
Support
bearings
Clutch cover
Belt cover
Mobile tensioners
Inner covers
Head oil tube
Exhaust
flange
Valve covers
Shaft covers
Rocker arm shafts
Rocker arms
Horn support horiz.
head water connector
Main bearings
