Ducati STREETFIGHTER V4 User Manual

TRIP FUEL
The TRIP FUEL function is only available when the
bike  using the fuel reserve and displays the
distance run from the moment the low fuel warning
light turns on, together with the set unit of
measurement (km or mi).
It is possible to change unit of measurement
through the “Units” function in the “SETTING
MENU”.
The function is disabled when the bike is no longer in
a low fuel condition.
The value referred to the distance run on fuel reserve
can be reset in the following cases:
- if value exceeds full scale value (9999.9);
- if user changes unit of measurement through
the SETTING MENU;
-   disconnection.
Note
The TRIP FUEL function is displayed
automatically at the precise moment when the bike
 using the fuel reserve, regardless of the
function currently displayed.
At any rate, it is possible to scroll through all the
other functions using the navigation 
Note
The TRIP FUEL function is not displayed
automatically when the SETTING MENU is open or
during override through the Pin Code.
Note
If the low fuel condition no longer applies while
TRIP FUEL function is displayed, the instrument
panel displays again the TOT function.
Lap Off
0
11:34
A.M.
Gear
km/h
N
DTC 2
DQS OFF
DWC 8
LO HI
RACE
RPM X 1000
10
9
8
7
6
5
4
3
2
1
11
12
13
14
15
TRIP 2 km
1432.2
TRIP FUEL
km
135.1
°CT AIR
22
Fig 31
81

Ducati STREETFIGHTER V4 Specifications

General

Displacement	1103 cc
Frame	Aluminum alloy Front Frame
Engine Type	Desmosedici Stradale 90° V4
Power	208 hp @ 13, 000 rpm
Torque	123 Nm @ 9, 500 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down
Seat Height	845 mm
Fuel Tank Capacity	16 liters
Front Suspension	Showa BPF fork, Ø 43 mm
Rear Suspension	Sachs monoshock, fully adjustable
Front Brake	2 x 330 mm semi-floating discs, Brembo Monobloc Stylema M4.30 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
