Ducati Supersport 950 User Manual

Adjusting the rear-view mirrors
Manually adjust the rear-view mirror by pushing at
points (A).
It is possible to close the rear-view mirrors, from the
open position (B), by acting on the shell and turning
inwards, to the  position (C, closed) of the
mirror.
A
Fig 177
B C
Fig 178
192

Ducati Supersport 950 Specifications

General

Power	110 hp (81 kW) @ 9, 000 rpm
Transmission	6-speed
Rear Brakes	245 mm disc, 2-piston caliper
Torque	93 Nm (68.6 lb-ft) @ 6, 500 rpm
Frame	Steel Trellis frame
Front Suspension	Marzocchi 43 mm fully adjustable USD fork
Front Brakes	2 x 320 mm semi-floating discs, radially mounted Brembo monobloc calipers
Dry Weight	184 kg (405 lbs)
Wet Weight	210 kg (463 lbs)
Seat Height	810 mm (31.9 in)
Fuel Tank Capacity	16 l (4.2 US gal)
Engine Type	Testastretta 11° L-Twin
Rear Suspension	Sachs monoshock, adjustable for preload and rebound
