33
Uni-Seeder Complete Assembly
Item Part No. Description Qty.
1 Refer page 30 Pedestal Leg Drive Assembly 1
2 Refer page 32 Wheel Leg Drive Assembly 1
3 Refer page 34 Seeder Tube Mounting Frame 1
4 Refer page 36 Drive Chains 1
5 Refer page 38 Hectaremeter Kit 1
6 Refer page 39 Seed Box Drive Shaft 1
7 Refer page 40 Gearbox Final Assembly 1
8 Refer page 42 Seedbox Assembly 1
9 Refer page 44 Agitator Drive 1
10 Refer page 45 Agitator Shaft Assembly (Inside Seedbox) 1
11 Refer page 46 Seeder Mechanism 19, 21 or 23
12 Refer Table Calibration Tray 1 or 2
13 26103 Drive Guard 1
14 45341 Nut, Wing, M10 1
15 25962 Pedestal Welded Assy, LH 1
16 25978 Drive Pedestal Welded Assy 1
17 22051 Crank Arm and Handle Assy 1
Pt. No. 67355
Issue 0906
Item 2.5m 3m 3.5m
12 22562 22563 22564
(one only) & 22571 (two)
