3
Pt. No. 67355
Issue 0906
* This includes groundwheel &
widths will vary slightly to suit
host machine. The groundwheel
is kept as close as possible to
host machine.
Description of Machine
The Duncan Uni-Seeder is a seeding system
designed to be fitted over a variety of implements.
A ground driven peg wheel supplies drive via chain
transmission to the Duncan variable speed
gearbox, which in turn drives the seeder units.
There is a choice of high or low drive ratios into
the gearbox easily changed using dual sprockets.
The seed is fed down flexible tubes to be finally
broadcast on the ground just in front of the
crumbler or packer roller. The high quality
European peg roller seeder system handles all
seed from turnip and rape through to peas and
maize. For transport or if the groundwheel is not
required the wheel and arm can be raised and held
in the up position
Working Principle
To give maximum flexibility and accuracy of
seeding rate the drive ratio, gearbox, seedbox
slides, pegged seed rollers and seeder flaps are all
adjustable and easily set. The seed is fed down
flexible tubes and broadcast onto the ground.
Specification
Dimensions & Capacities
Uni-Seeder Model 19 Run 21 Run 23 Run
Host machine width 2.5m 3.0m 3.5m
Width over sowing system* 3.025m 3.325m 3.825m
Number of runs 19 21 25
Weight (unladen) 150 kg 180 kg 210 kg
Box capacity (litres) 348 442 536
