Uni-Seeder Pedestal Leg Drive Assembly
Item Part No. Description Qty.
1 26180 Pedestal Leg Assembly 1
2* 26188 Leg Joiner Assembly 1
3 22281P Cover Plate Profile 1
4 26192 Folded Endcap 1
5 26160 Chain Tensioner Arm 1
6 26162 Chain Tensioner Roller 1
7 26200 Transfer Shaft 1
8 26201 Dummy Shaft 1
9 26198 21T Sprocket 1/2”P x 25mm Bore 1
10 22043 15T Sprocket 1/2”P x 25mm Bore 1
11 43386 Y Bearing YET 205 3
12 30359 Bearing Housing P52 (Pr) 3
13 26196 1/2” BS Chain x 97 Links 1
14 43388 1/2” Pitch Joiner Link 1
15 22294 Sprocket Key (6x6x25) 2
16 26165 Tensioner Handle 1
17 26166 Tensioner Plunger Rod 1
18 26167 Tensioner Spring 1
19 45391S M8 x 12 Set Screw 9
20 45410S M8 x 16 Set Screw 10
21 45165 M8 Spring Washer 19
22
23
24 45151 M8 Light Flat Washer 2
25 45180 M8 x 10 Socket Head Grubscrew 2
26 45123 M8 Hex Nut 1
27 45133 M20 Hex Nut 1
28 45415 M8 x 45 Class 4.6 Bolt 1
29 45186 M10 x 12 Socket Head Grubscrew 2
Pt. No. 67355
Issue 0906
* Note: There is only one Leg Joiner Assembly per machine (Item 2)
