Uni-Seeder Wheel Leg Drive Assembly
Item Part No. Description Qty.
1 26173 Wheel Leg Assembly 1
2* 26189 Leg Joiner Assembly 1
3 22281P Cover Plate Profile 1
4 26192 Folded Endcap 2
5 26160 Chain Tensioner Arm 1
6 26162 Chain Tensioner Roller 1
7* 26191 Layshaft (Kvernland) 1
8 26147 Key (Drive Wheel) (6x6x40) 1
9
10 22043 15T Sprocket 1/2”P x 25mm Bore 2
11 43386 Y Bearing YET 205 3
12 30359 Bearing Housing P52 3
13 26150 1/2” BS Chain x 85 Links 1
14 43388 1/2” Pitch Joiner Link 1
15 22294 Sprocket Key(6x6x25) 2
16 26165 Tensioner Handle 1
17 26166 Tensioner Plunger Rod 1
18 26167 Tensioner Spring 1
19 45391S M8 x 12 Set Screw 13
20 45410S M8 x 16 Set Screw 12
21 45165 M8 Spring Washer 25
22
23
24 45151 M8 Light Flat Washer 4
25 45180 M8 x 10 Socket Head Grubscrew 5
26 45123 M8 Hex Nut 1
27 45133 M20 Hex Nut 1
28 45415 M8 x 45 Class 4.6 Bolt 1
29 26194 Bearing Mount Plate 1
30 26142 Drive Wheel Assembly 1
31 26145 Wheel Retaining Plate 1
32 45433S M12 x 30 Set Screw 1
33 45167 M12 Spring Washer 1
34 26146 Wheel Shaft 1
Pt. No. 67355
Issue 0906
* Notes:
1. There is only one Leg Joiner Assembly per machine (Item 2)
2. 26188 and 26190 replace 26189 and 26191 respectively
when smaller offset is used (Items 2 and 7).
To Next Page
