Installation:
⑥ Slide T shape bolts into the middle hole of rail,
with U-Shape Stator, M8 Arc Washer, M8 Flat
Washer, and Plastic Nut lightly screwed in
advance.(as P2)
⑦ Screw the other side of U Shaped Stator with
component in order as above, and ensure Stator
tightened(as P3, same operation for rest).
⑤ Slide the T shape bolts into the rails from
two sides(as P1).
M8 Arc Washer
M8 Flat Washer
④
P1
P2
-2-
EN
To Next Page
