16
6. Using the DC-6 mini, DC-8 mini
This switch operation cannot be performed
when the downstream processing device is not
connected.
6 Select “ON” or “OFF” with the
downstream processing switch key.
• Select “ON” when using a downstream processing
device.
• Select “OFF” when the downstream processing device
is not used.
This operation cannot be performed when the
downstream processing switch key is “ON”.
• Select the mode “Straight Stack” when not clustering
the paper.
7 Select cluster stack or straight stack
with the paper receiver select key.
• Select the mode “Cluster Stack” when clustering the
paper.
The paper receiver tray moves automatically to
the appropriate position when it is not at the
proper position. The mode “Cluster Stack”
cannot be selected while the paper receiver
tray is moving.
