SERVICE MODE LIST
This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily.
To enter the Service Mode, press both set key and remote control key for more than 2 seconds.
Set Key
Remocon Key Operations
VOL. (-) MIN
0
Releasing of V-CHIP PASSWORD.
VOL. (-) MIN 1
Initialization of factory data.
NOTE:
Do not use this for normal servicing.
If you set factory initialization, the memories are reset such as the channel
setting, and the POWER ON total hours.
Check of the SUM DATA and MICON VERSION on the screen.
Refer to the " WHEN REPLACING EEPROM (MEMORY) IC ".
8
VOL. (-) MIN
VOL. (-) MIN
6
Check for the firmware version.
Can be checked of the INITIAL DATA of MEMORY IC.
Refer to the
" WHEN REPLACING EEPROM (MEMORY) IC ".
VOL. (-) MIN
Display of the Adjustment MENU on the screen.
Refer to the "ELECTRICAL ADJUSTMENT" (On-Screen Display Adjustment).
9
ADDRESS DATA
POWER ON total hours.
= (16 x 16 x 16 x thousands digit value)
+ (16 x 16 x hundreds digit value)
+ (16 x tens digit value)
+ (ones digit value)
1.
2.
3.
4.
Turn on the POWER, and set to the TV mode.
Set the VOLUME to minimum.
Press both VOL. DOWN button on the set and Channel button (8) on the remote control for more than 2 seconds.
After the confirmation of each check sum, power on total hours, digital tv micon firware and micon version, turn off the
power.
Initial total of MEMORY IC, POWER ON total hours, MICON VERSION and Digital TV MICON Firmware VERSION can be
checked on the screen. Total hours are displayed in 16 system of notation.
NOTE:
WHEN REPLACING EEPROM (MEMORY) IC
If you set a factory initialization, the total hours is reset to "0".
Please refer to "CONFIRMATION OF INITIAL DATA" when SUM DATA is not corresponding.
FIG. 1
INIT 00 D0
CRT ON 0000
OEC7177A_025
DTV CA00E71091
INIT 251D
ROM: 0000
MICON Version
Initial setting data check sum.
Rom correction data check sum.
Digital TV MICON Firmware
CONFIRMATION OF CHECK SUM, POWER ON TOTAL HOURS, MICON VERSION AND
DIGITAL TV MICON FIRMWARE VERSION
Initial setting content of MEMORY IC.
NOTE:
The each item value might be different according to each set.
