Duralast T82454S - Trolley Jack Assembly Diagram; Trolley Jack Parts List

ASSEMBLY DIAGRAM-Trolley Jack
REF#
PART#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
QLQD2A.1-1
T82004C.4
T82000-1a
GB894.1
GB91
QLQD2A.7-2
QLQD2C.5-2a
GB894.1
GB6170
GB97.1
T820013-7
T820033XE-4
Handle cover
Handle
Cover plate
Supporting shaft
Pin for frame
Supporting shaft
Connecting rod
Lifting arm assembly
C-clip Ø 18mm
Cotter pin Ø 2x20mm
Saddle
Saddle pin
C-clip Ø 13mm
Right frame assembly
Washer M12
Nut M12
Washer M12
Sleeve for front wheel
Front wheel
1
1
1
1
1
1
2
1
2
1
1
1
2
1
4
6
2
2
2
DESCRIPTION QTY
REF#
PART#
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
QLQD2B-3
T820033XE.2(asm)
TF1201C-29
TA82504D.1
GB308-6
T83003.2-10(asm)
QLQD2A.2-5(asm)
QLQD2A.2-7b
QLQD2A.2-8b
TA820012.1-23
QLQD2A.2-19
QLQD2A.2-20
TA82504D.MF
Roundwire snap ring Ø 1.4x26mm
Saddle base assembly
Pin for saddle base
Shaft for front wheel
Pin for lifting arm
Rear caster assembly
Left frame assembly
Return spring
Oil plug
Power unit assembly
Steel ball bearing Ø 6mm
Release value assembly
Pump plunger assembly
U-Bracket for plunger
Handle socket
Cotter pin Ø 2X14mm
Pin for pump plunger
Pin for unit base
Seal kit
4
1
1
1
1
2
1
1
1
1
1
1
1
1
1
2
1
1
1
DESCRIPTION QTY
Safe Operating Temperature is between 40°F – 105°F (4°C - 41°C)
