EXPLODED VIEW/PARTS LIST
28
Item No. DescriptionPart No. Qty.
1 Motor cover assy.31101239 1
1-1 Screw M5X143221050 4
1-2 Motor cover strip seal3420235
1-3 Motor cover34101239
1
1
5-3 Bolt M6X123220137 3
2 Screw3220404 1
3 Rectifier3690135 1
4 Radiator rectifier3331035 1
5 12A motor (20'')3610138-1 1
5-1 Carbon brush3110638-3 2
5-2 Self locking nut M63220537 3
6 Deck31301239 1
7 Screw M5X103220575 4
8 Self locking nut M53220439 4
9 18 in front wheel axle (12A)3110137-2 1
10 Extension spring3340137-1 1
11 18 in link bar3330537-2 1
12 7 in wheel cover34104227-3 4
13 Pin3290135 4
14 Washer 13.5X20X1.53331638 4
15 7 in wheel34201221-2 4
16 Front wheel ferrule (B)3320237 4
17 Self locking nut M63220537 2
18 Spindle guard3320238 1
19 Fan3410237 1
20 Blade3330137 1
21 Blade insulator3410535 1
22 Spacer3331435 1
23 Blade nut3221037 1
24 Bolt3221637 4
25 Height adjustment bracket left3330737-1 1
26 Flange nut3220737 4
27 18 in rear wheel axle (12A)3110237-2 1
28 Self locking nut M43221237 2
29 Washer3330391 2
30 Wire clip3330490-1 2
31 Screw M4×123220511 2
32
33
Rear flap3420237-1
31102239
1
1
33-1
Self locking nut M53220439 4
33-2
Spring board3330437-1 1
33-3
Screw M5×153220608 4
33-4
Height adjustment shaft
Height adjustment handle assy.
3220137-2 1
33-5
33-6
Handle upper cover34113227 1
Handle lower cover34114227 1
