Duramaxx 84881 User Manual

EXPLODED VIEW/PARTS LIST
29
Item No. DescriptionPart No. Qty.
36 Height adjustment bracket right
3330837-1 1
37 Knob3410835-4 4
38 Bolt3220436 2
39 Upper handle assy.3110939 1
39-1 Soft grip sponge3490137 1
40 Switch assy.3111590 1
40-1 Screw3220105 3
40-2 Screw3220437 2
40-3 Cord retainer34106227 1
40-4 Switch lower cover3410690-2 1
40-5 Switch3630135-1 1
40-6 Switch upper cover3410590-2 1
40-7 Switch idler wheel3630336 1
40-8 Switch trigger3410194 1
40-9 Switch spring3340437 1
40-10
Self-locking spring3340337 1
40-11
Switch self-locking button3410294 1
40-12
Trigger privot3410494 1
40-13
Screw3220735 1
40-14
Washer3290305 1
40-15
Wire clip3411435 2
40-16
Screw3220505
40-17
Overload protector36501227
4
1
41 Cord with plug assy.3111190 1
42 Motor cable assy.3111290 1
43
44
Inner cord assy.3111390 1
45
Bolt M6X83220136 2
46
Side discharge assy.
3111490 1
47
Side discharge chute
3410637 1
48
Screw M4×123220511 1
49
Resistance radiator3331437 1
50
Resistance bracket36901227 1
51
Spring washer3290675 1
52
Nut M43290105 1
53
Self locking nut M53220439 2
54
Resistance support3410290-1 1
55
Screw M5X203220850 2
56
Screw3220951 2
57
Screw3220105 2
58
Cord retainer3410403 1
59
Self locking screw M5X123221137 2
Cord guide3410137 1
34 Cord guide3411135 2
35 Lower handle33301239 1
