ELECTRICAL
WARNING:
Keep the extension cord clear of the working area. Position the
cord so that it will not get caught on lumber, tools, or other obstructions while you are
working with a power tool. Failure to do so can result in serious personal injury.
WARNING:
Check extension cords before each use. If damaged replace
immediately. Never use the product with a damaged cord since touching the damaged
area could cause electrical shock resulting in serious injury.
9
**Ampere rating (on product data plate)
0-2.0 2.1-3.4 3.5-5.0 5.1-7.0 7.1-12.0 12.1-16.0
**Used on 12 gauge - 20 amp circuit.
NOTE: AWG = American Wire Gauge
Cord Length Wire Size (A.W.G)
25' 16 16 16 16 14 14
50' 16 16 16 14 14 12
100' 16 16 14 14 12 _
