Instruction Manual
RG Series SA CT Cylinder - V1.4 www.durapac.com Page 7 of 26
5.2.4 Non synchronised lifting actions
5.2.5 Non stable cylinder base support.
To reduce cylinder offset loading, optional tilt saddles are available. Always use grease
underneath swivel saddles.
Figure 3 – Tilt Saddle.
6.0 Maintenance
Use only good quality hydraulic fluid. Do NOT use brake fluid, transmission fluid,
turbine oil, motor oil, alcohol, glycerine etc. Use of anything other than good quality
hydraulic oil will void warranty and damage the cylinder and application. We
recommend Durapac Hydraulic Oil or equivalent
Equipment must only be serviced by a qualified hydraulic technician. For repair service,
contact your local Durapac authorised service centre
Damage to hydraulic hoses may not be detected during visual inspections. For this
reason, Durapac recommends that hydraulic hoses be replaced on a regular basis
Tighten connections as needed. Use non-hardening pipe thread compound when
servicing connections
Dirt, sand, etc. will quickly ruin any hydraulic system. Ensure that couplings are clean and free of
foreign matter. After each use, clean couplings and attach dust caps.
Maintenance is required when wear or leakage is noticed. Periodically inspect all components to
detect any problem that may require service and maintenance.
6.1 Check for loose connections and leaks.
6.2 Replace damaged parts immediately.
6.3 Do not exceed oil temperature above 60
o
C.
6.4 Keep all hydraulic components clean.
6.5 Use dust caps when cylinder is disconnected from the hose. Keep entire cylinder clean
to prolong cylinder life.
6.6 Wipe thoroughly clean and store cylinders upright (to prevent seal distortion) in a
clean, dry environment. Avoid temperature extremes.
6.7 Change hydraulic oil in your system as recommended in the pump instruction sheet.
