305 mm
12"
> Inspect product for any potential
damage that may have occurred
during transport.
> Do not install if any damage is
visible.
> Install shut-off valve and closet
flange according to instructions.
> Remove tank lid to prevent
damage during installation.
> Install water supply line either
through the hole or behind the
toilet pending model.
> Connect the supply line to the fill
valve.
> Install wax ring and T-bolts
according to instructions.
NOTICE
Risk of external leaks!
> Do not lift or rock the toilet after
placement.
> If you break the watertight seal,
you must install a new wax seal.
> Install toilet to floor flange.
6 MI_70000732_57310_22.12.4
1 2 3
4 5 6
