5) Next, slide the hanging brackets into place.
There are either 4 of them included, 2 for the top frame
and 2 for the bottom.
These brackets will be used later to hang the screen on
to the wall.
6) Next, join all of the sides together. Using the
L-joiners, slide one part into the top frame rail and the
other part into one of the side frame rails. Secure in
place using 4 joiner screws and tighten them into place
using the Allen key.
Repeat the same for every corner of the frame, so that
all pieces of the frame rails are joined together.
Prepare the Screen
7) Check rst that the oor is clean and dry. Gently unroll the screen and lay it
down on the oor with the viewing side face-down.
8) Starting with the single-ended rods, attach two together as shown to create
a long rod:
