DUSTLESS BLASTING DB800 - Installation and Operation Overview; Model DB800 Figures

To Next Page

To Previous Page

Carefully read the INSTALLATION, OPERATING, and MAINTENANCE directions supplied with the machine from the factory.

If you do not have a copy, please contact your employer (supervisor) or the MMLJ Inc. Company.

This system will mix clean water, rust inhibitor, and abrasive together. The DB800

is designed to hold:

• 30 gallons of clean water

• 300 lbs of Abrasive, mesh size approx. 50/70

• 42 oz of Rust Inhibitor

INSTALLATION AND

OPERATING INSTRUCTIONS

PLEASE READ CAREFULLY BEFORE OPERATING

16 15

MODEL DB800® FIGURES

1. Pinch Hose

2. Control Box Input Couplings

3. Fill Port

4. Blowdown Valve

5. Air Inlet Valve

6. Compressed Air Inlet

7. Compressed Air Pressure Gauge

8. Pressure Regulator

9. Control Box

10. Blast Pressure Gauge

11. Rocker Arm

12. Vibrator

13. Bottom Flange

14. Overow Valve

15. Pinch Valve

16. Abrasive Control Knob

17. Vibrator Valve

18. Moisture Trap
