Dustsilver D66 Keyboard

The Dustsilver D66 is a mechanical keyboard designed to "make input more ritualistic," offering a blend of aesthetic customization, versatile connectivity, and user-friendly features. This instruction manual provides a comprehensive overview of its specifications, packaging contents, pairing and connection procedures, and common key combinations.

Function Description

The Dustsilver D66 keyboard is a versatile input device supporting multiple connection modes: 2.4G wireless, Bluetooth, and wired (USB Type-C). It is compatible with a wide range of operating systems, including Windows, Mac OS, Android, and iOS, making it suitable for various devices and user preferences. The keyboard emphasizes user customization through its "Keyboard painter card," encouraging users to personalize the design, and offers dynamic backlighting effects that can be adjusted or switched via key combinations or a control program.

A unique feature of the D66 is its integrated knob, which by default controls volume. A short press mutes the audio, while a long press (3 seconds) switches its function to adjust the main backlight brightness. This dual-function knob enhances user convenience by providing quick access to essential controls.

The keyboard also includes indicator lights for key functions. A green light on the upper part of the indicator bar signifies when Capslock is active. A blue light on the lower half of the indicator bar indicates that the WIN key is locked (activated by Fn + WIN), which can be unlocked by repeating the combination. Additionally, the indicator lights provide visual feedback on battery status: red for low battery, green for charging, and RGB for normal power, including a dynamic spectrum cycle for lighting effects.

Important Technical Specifications

Product Name: DUSTSILVER D66
Product Size: 322.8 * 116.7 * 36.7 (mm)
Weight: ≈ 720 (g)
Number of Keys: 66
Battery Capacity: 3000mAh
Working Voltage: DC5V
Operating Current: ≤ 400mA
Connection Modes: USB TYPE-C/Bluetooth/2.4G
System Support: Windows/Mac OS/Android/iOS
Bluetooth Device Names: Bluetooth 5.0:D66 KB 5.0 / Bluetooth 3.0:D66 KB 3.0
Wired Device Name: D66 KB
2.4G Device Name: 2.4G Wireless Keyboard

Usage Features

Connectivity:

The D66 offers three primary connection modes, selectable via a physical switch on the keyboard:

2.4G Wireless Mode: Connects via a dedicated 2.4G signal receiver. Users simply plug the receiver into a USB port, and the device connects automatically. If a non-factory receiver is used, a matching operation is required: long press Fn+R for 3 seconds until the backlight flashes, activating the 2.4G signal band. The backlight returns to normal upon successful connection.
Wired Mode: Connects directly via a USB Type-C cable. The Type-C end plugs into the keyboard, and the USB end into the host device.
Bluetooth Wireless Mode: Supports up to three Bluetooth devices. To pair, users long press Fn + Q/W/E for 3 seconds. The corresponding key's backlight will flash (red for device 1, blue for device 2, yellow for device 3), indicating activation of the Bluetooth signal band. Users then open the Bluetooth connection interface on their device, select "D66 KB 5.0" or "D66 KB 3.0," and connect. The backlight returns to normal after successful pairing.

Key Combinations (Windows / Mac OS):

The keyboard features numerous Fn key combinations for enhanced functionality:

Fn+Esc: Long press for 3 seconds to restore factory settings.
Fn+1 (F): Increase screen (Mac OS).
Fn+2 (F): Lower the screen (Mac OS).
Fn+3 (F): Task menu (Mac OS).
Fn+4 (F): Search (Mac OS).
Fn+5 (F):): Siri (Mac OS).
Fn+7 (F): Previous song (Mac OS).
Fn+8 (F): Pause/Play (Mac OS).
Fn+9 (F): Next song (Mac OS).
Fn+0 (F1): Mute (Mac OS).
Fn+-_ (F1): Volume down (Mac OS).
Fn+=+ (F12): Raise the volume (Mac OS).
Fn+Backspace: Check power (wireless connection mode only).
Fn+M: Switch to Mac system.
Fn+D: Switch to Windows system.
Fn+S: Switch the main backlight effect.
Fn+Tab: Turn on/off the backlight.
Fn+↑: Increase the main backlight brightness.
Fn+↓: Decrease the main backlight brightness.
Fn+←: Decrease the main backlighting speed.
Fn+→: Increase the main backlight speed.
Fn+,<: Insert.
Fn+.>: Home.
Fn+/?: End.
Fn+L: PrtSc (Windows).
Fn+;: : ScrLk (Windows).
Fn+' ": Pause (Windows).
Fn+T: Player (Windows).
Fn+Y: Previous song (Windows).
Fn+U: Pause/play (Windows).
Fn+I: Next song (Windows).
Fn+O: My Computer (Windows).
Fn+P: Browser (Windows).
Fn+[{: E-Mail (Windows).
Fn+]} : Calculator (Windows).
Fn+Q: BT1 (Mac OS).
Fn+W: BT2 (Mac OS).
Fn+E: BT3 (Mac OS).
Fn+R: 2.4G (Mac OS).
Fn+A: Switching the main backlight color.
Fn+Z: Switch the light effect of the LOGO decorative light.
Fn+X: Switch the color of the LOGO decorative light.
Fn+Pg Up: Increase the brightness of the LOGO decorative light.
Fn+Pg Dn: Decrease the brightness of the LOGO decorative light.

Power Check:

To check the remaining battery power (only in wireless connection mode), press Fn+Backspace. The keyboard backlight will turn off, and the number keys '1' through '0' will light up, with each key representing 10% of the battery level. For example, if keys '1' through '6' are lit, the battery has 60% remaining.

Packaging Contents:

The D66 keyboard comes with a comprehensive set of accessories:

Keyboard painter card: For user customization of the keyboard design.
Transparent dust cover: To protect the keyboard when not in use.
D66 Keyboard: The main device.
Accessory box containing:
- Wireless 2.4G signal receiver.
- 1.8m Type-C data cable.
- Data cable conversion plug.
- 2-in-1 keycap/switch puller.
- Paper user manual.
- Multi-language electronic manual scan card (via QR code).
- Replacement keycaps for macOS users.
- Keyboard Keychain Charm.

Maintenance Features

The Dustsilver D66 is designed with environmental considerations in mind, adhering to RoHS testing and compliance. The company emphasizes environmentally friendly material application, using recyclable materials and optimizing the design to reduce packaging weight and lighten instruction manuals. This commitment to sustainability contributes to the product's overall maintenance and lifecycle. The inclusion of a transparent dust cover helps protect the keyboard from dust and debris, prolonging its lifespan and maintaining its aesthetic appeal. The 2-in-1 keycap/switch puller facilitates easy cleaning and maintenance of keycaps and switches, allowing users to keep their keyboard in optimal condition.
