I
NSTRUCTIONS D’ASSEMBLAGE
A
SSEMBLY INSTRUCTIONS
299 Chaput
St-Pie (Québec)
Canada
J0H 1W0
450 772-2403, Fax 450 772-5055
info@dutailier.com
MODÈLE :
MODEL :
KEEP THESE INSTRUCTIONS AND EXTRA HARDWARE FOR FUTURE USE
GARDER CES INSTRUCTIONS AINSI QUE LA QUINCAILLERIE SUPPLÉMENTAIRE
POUR UTILISATION FUTURE
REV:03 Fev 2017
133249
QUINCAILLERIE / LISTE DES PIÈCES
HARDWARE / PARTS LIST
Page /
Brevet U.S. No.9.138.068
U.S. Patent No.9.138.068
LIT SIMPLE
TWIN BED
LIT SIMPLE
TWIN BED
E8040C5 E8140C5
E8240C5 E8340C5
E8440C5 E8450C5
E8000K5
18
VIS À BOIS 1 1/4'' (32 mm) LONG
WOOD SCREW 1 1/4'' (32 mm) LONG
8x
Tournevis Phillips nécessaire (non inclus)
Phillips screwdriver needed (not included)
CLÉ ALLEN 5/32" (4mm)
ALLEN KEY 5/32" (4mm)
25
7
VIS 1 3/16'' (30 mm) LONG
SCREW 1 3/16'' (30 mm) LONG
6x
1x
10
RONDELLE D'ARRÊT
LOCK WASHER
22x
9
VIS 2'' (50 mm) LONG
SCREW 2'' (50 mm) LONG
4x
8
VIS 1 9/16'' (40 mm) LONG
SCREW 1 9/16'' (40 mm) LONG
12x
9
(#603286)
(#603285)
(#603287)
(#603162)
(#601002)
(#60044)
