Dutton-Lainson DLB800A - Parts List

PARTS LIST
Ref Description Part No.
A Base 404900
*
A Base – DLB 350AG 404945
*
B Bushing 204012
C “E” Ring 205116
D Drive Shaft 306061
E Spring 204364
F Handle – 7” 5703061
Handle – 9-3/8” 5703103
G Nut 205033
H Pressure Plate 204362
H Pressure Plate “G” Series 206620
J Ratchet Wheel 404164
K Pressure Washer 404163
L Bushing 206328
M Nut 205316
N Bolt 205332
P Rope Clamp Kit 5243506
Q Gear Cover – “G” Series 406114
S Reel 306075
*
Reel - DLB350AG 306167
T Locknut 204803
U Bolt 205167
V Flat Washer 205055
W Pawl 404409
Pawl – “G” Series 404190
X Spacer 404166
Spacer – “G” Series 404191
Y Spring 204363
Spring – “G” Series 204460
Z Reel Spacer 207183
AB Bolt 203161
AC Reel Spacer 204807
AE Reel 306062
*
AF Base 404893
*
Base – DLB 800AG 404895
*
Ref Description Part No.
AH Lockout Lever (optional) 404579
AJ Spacer (optional) 406160
AK Gear Cover (optional)
Painted Bronze 5240346
Plated 5240361
AL Base 404896
*
Base – DLB 1200AG 404897
*
AM Bushing 204009
AN Gear Cover – “G” Series 406115
AQ Gear Cover (optional)
Painted Bronze 5240122
Plated 5240221
AR Spacer Washer 205120
AS Reel 304754
*
AS Reel – 1-7/8” (optional) 304768
*
AT Base 404891
*
Base – DLB 1500AG 404892
*
AU Drive Shaft 304760
AV Handle – 9-3/8” 5703103
Handle – 12” 5703111
AW Bolt 204804
AX Reel Spacer 204808
AY Gear Cover (optional)
Painted Bronze 5240387
Plated 5240403
AZ Reel 304755
*
BA Base – DLB2500A 406047
*
Base – DLB 2000AG 404899
*
BB Spacer 404434
BC Bolt 205006
BD Flat Washer 205139
BE Intermed. Drive Shaft 306035
BF Nut 205014
BH Reel 304756
*
BJ Drive Hub (Optional) 304562
BM Handle w/Lock Pin (Opt) 5703426
BN Handle Hub (Optional) 304630
BP Special Nut (Optional) 404970
BQ “E” Ring 206162
BR Bushing 206163
BS Bolt 205335
*
Specify Color When Ordering
