Duux Whisper Flex - Installation; Fan Head and Grill Assembly

5
2. Installation
2
Attach the fan blades to the motor.
3
Use the plastic screw to secure the fan blades.
Note: turn the screw anticlockwise rmly to
secure it.
1
Place the rear grill over the motor and tighten
with the locking ring.
EN
4
Fit the front grill and rotate it a little, clockwise,
until the arrow on the grill lines up with the
left-side marker.
